Superior De-aeration Performance
Lock & Key Quality Protected Elements
Used on the AFT and AFTF Hydraulic In-Tank Filters
Excellement Z-Media (Synthetic Microglass)

1 - 4 of 4 | Results Per Page | View | Unit of Measure

1

Request Information Compare Items

Item #	Item Name	LIST_PRICE	Seal Material	Weight	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	Filter Rating	Beta Ratio	Quality Protection	Media Type	Element Collapse Pressure	Filter Rating - Beta Ratio	Diameter	Height	Inner Diameter	Add To Cart/Request Quote

7647483	N/A 8LKZ3,ELEMENT	QUOTE	N/A Buna	N/A 0.52 kg1.15 lb	N/A -29 ºC-20 ºF	N/A 107 ºC225 ºF	N/A 99.9 %	N/A 3 µm	N/A 1000	N/A Lock & Key	N/A Excellement® Z-Media® (Synthetic)	N/A 10.3 bar150 psi	N/A 4.8	N/A 3.7 in94 mm	N/A 7.8 in199 mm	N/A 1.3 in32 mm	Request Quote
7647484	N/A 8LKZ5,ELEMENT	QUOTE	N/A Buna	N/A 0.52 kg1.15 lb	N/A -29 ºC-20 ºF	N/A 107 ºC225 ºF	N/A 99.9 %	N/A 5 µm	N/A 1000	N/A Lock & Key	N/A Excellement® Z-Media® (Synthetic)	N/A 10.3 bar150 psi	N/A 6.3	N/A 3.7 in94 mm	N/A 7.8 in199 mm	N/A 1.3 in32 mm	Request Quote
7645657	N/A 8LKZ10,ELEMENT	QUOTE	N/A Buna	N/A 0.52 kg1.15 lb	N/A -29 ºC-20 ºF	N/A 107 ºC225 ºF	N/A 99.9 %	N/A 10 µm	N/A 1000	N/A Lock & Key	N/A Excellement® Z-Media® (Synthetic)	N/A 10.3 bar150 psi	N/A 10	N/A 3.7 in94 mm	N/A 7.8 in199 mm	N/A 1.3 in32 mm	Request Quote
7647485	N/A 8LKZ25,ELEMENT	QUOTE	N/A Buna	N/A 0.52 kg1.15 lb	N/A -29 ºC-20 ºF	N/A 107 ºC225 ºF	N/A 99.9 %	N/A 25 µm	N/A 1000	N/A Lock & Key	N/A Excellement® Z-Media® (Synthetic)	N/A 10.3 bar150 psi	N/A 24	N/A 3.7 in94 mm	N/A 7.8 in199 mm	N/A 1.3 in32 mm	Request Quote
